FUNCTION :
This valve is designed at no leakage type by valve operation
for back flow prevent of system. Used on compressor
equipment and no leakage. Soft seat used on. |
|
| ¡Ü Specification |
| Model |
KBP-FL |
| Type |
Cage |
| Applicable Fluids |
Compressed Air |
| Applicable Press. / Temp |
30 kgf/cm2 80¡ÆC |
| Material |
Body |
Cast Steel |
| Trim |
Stainless Steel |
| Mesh(Screen) |
20, 40, 60, 80, 100 |
| Rating(kgf/ )/Size |
JIS 30K / 40~50 |
|
| |
| ¡Ü Dimensions |
| (mm) |
Size
mm(inch) |
d |
L |
H |
Weight
(Kg) |
| 40(1 1/2 ¡±) |
40 |
240 |
435 |
19 |
| 50(2") |
50 |
260 |
140 |
23 |
|
 |
| |
|
|
