FUNCTION :
This items are angle/globe type for manual open/close in according
to system installed. The divides function into stationary type and check type.
¡°It is applied JIS CODE¡± We, KORVAL, do manufacture & supply
CONTROL VALVE UNIT per each ITEM for the satisfying our
customer's needs.
We do our best to supply for customer¡¯s management competition,
Assembly, Exacting quality control. |
|
¡Ü Specification |
| Model |
PGL-FG |
PAN-FG |
| Type |
Globe |
Angle |
| Applicable Fluids |
Steam, Compressed Air |
| Applicable Press. / Temp |
40kgf/cm2 / 220¡ÆC |
| Material |
Body |
Forged steel (SF440) |
| Trim |
Stainless Steel |
| Size |
15~40 mm15~25 mm |
| Applicable Standard No. |
JIS F7421, F7336 |
JIS F7422, F7337 |
|
| |
| |
|
|
