It can be used Both of Dividing type and mixing type by flow direction of fluid in a
system. The Valve Which is spring return type is operated by air pressure
existence or nonexistence at actuator. As this operation, The main valve
will be operated “OPEN/CLOSE” and the type is division by valve installed
direction. |
● FEATURE
1) Emergency operating is possible with emergency handle devices.
2) No leakage and strongly
3) One valve has Two kind of ability.
4) Various function is possible with accessories |
| |
| ● Specification |
| Model |
KC3-ST, EB |
KC3-YK |
| Type (Spring Return) |
Cylinder ( Straight, Elbow) |
Cylinder ( Straight) |
| Applicable Fluid |
Water, Steam, Oil |
| Applicable Press. / Temp. |
5 kgf/cm2 / 160℃ |
10 kgf/cm2 / 220℃ |
| Air supply Pressure |
Air supply (B -> C) / Air less (B -> A) |
| Operation |
Dividing |
Air supply (B -> C) / Air less (B -> A) |
| Mixing |
Air supply (C-> B) / Air less (A-> B) |
| Material |
Body |
Ductile Cast Iron, Bronze, Cast Steel |
| Trim |
Stainless Steel |
| Size |
15~50 mm |
65~200mm |
| Accessories (Option) |
●Solenoid valve ●Limit switch ●Air set. |
|
| |
| ● Dimensions |
| (mm) |
| Model |
Size
mm(inch) |
d |
L |
G1 |
G2 |
H |
Weight
(Kg) |
KC3-ST
-EB |
15(1/2") |
15 |
154 |
110 |
135 |
295 |
19 |
| 20(3/4") |
20 |
158 |
110 |
135 |
295 |
21 |
| 25(1") |
25 |
160 |
115 |
140 |
295 |
24 |
| 32(1 1/4 ") |
32 |
190 |
150 |
160 |
295 |
27 |
| 40(1 1/2") |
40 |
190 |
150 |
160 |
295 |
40 |
| 50(2") |
50 |
220 |
158 |
178 |
295 |
50 |
| KC3-YK |
65(2 1/2") |
65 |
290 |
202 |
- |
830 |
71 |
| 80(3") |
80 |
310 |
213 |
- |
862 |
85 |
| 100(4") |
100 |
350 |
234 |
- |
960 |
118 |
| 125(5") |
125 |
390 |
260 |
- |
994 |
163 |
| 150(6") |
150 |
451 |
296 |
- |
1043 |
203 |
| 200(8") |
200 |
543 |
296 |
- |
1043 |
246 |
|
Notes :
1. Also available in JIS, DIN and ANSI. For all other standards please consult factory.
2. Weights(Ductile Cast Iron) are approximate and applied JIS 10K.
3. The flanges shall conform by JIS B2210. |
 |
| |
|
|
