● FEATURE
1) Installed simple and no auxiliary power is required
2) Handling is easy for occur of large capacity.
3) Suitability at difficult of access of people.
4) Leakage is no with check valve of high faculty.
5) This one has safety function by itself. So it can protect by itself. |
| |
| ● Specification |
| Model |
AHT-D1 |
AHT-D2 |
AHT-D3 |
AHT-D4 |
| Discharge (cc/rev.) |
13 |
26 |
42 |
64 |
| Max. Operation pressure |
120 kgf/cm2 |
| Open / Close pressure |
90 / 80 kgf/cm2 |
| Applicable Temperature |
-20~80℃ |
| Viscosity to Hydraulic Oil |
Mineral Oil, ISO VG22~32 |
| Oil Fill Capacity |
1200 |
250 |
1350 |
1400 |
| Approx. Weight(without oil) |
32 |
35 |
45 |
50 |
| Dimension |
ΦD |
315 |
355 |
355 |
450 |
| H |
700 |
| H1 |
300 |
| L |
210 |
| M |
180 |
| Accessories |
●Self seal coupling ● Lamp Box ● Manifold |
|
| |
| ● Dimensions |
| (mm) |
Size
mm(inch) |
d |
L |
M |
H1 |
H2 |
Weight
(Kg) |
| 100(4") |
100 |
312 |
156 |
120 |
290 |
54 |
| 125(5") |
125 |
348 |
174 |
120 |
290 |
80 |
| 150(6") |
150 |
378 |
189 |
180 |
340 |
104 |
| 200(8") |
200 |
460 |
150 |
190 |
375 |
150 |
|
 |
| |
